Detailed parameters:
| Model | Unit | WK026 |
|---|---|---|
| Grinding diameter range | mm | Φ80 ~ 800 |
| Teeth distance | mm | Φ7~100 |
| Thickness of blade | mm | 1~7 |
| Hole size | mm | φ10~200 |
| Feed speed | teeth /min | ＜20 |
| Outer diameter of grinding wheel | mm | φ125 |
| Front and back grinding angle range | deg. | 5°- 30° |
| Hydraulic working pressure | Pa | 4.0MPa |
| Rated capacity of oil tank | L | 50 |
| Speed of Grinding wheel | RPM | 4200 |
| Packaging size | mm | 1700 x 1350 x 1800 |
| Machine weight | kg | 900 |
